BY1248D

Direct-Connect DIN Rail Energy Meter

Available to order

Class 1 DIN rail kWh metering with Modbus/RTU. Confirm the current rating before ordering.

Current rating and connection type require confirmation before ordering.

Do not substitute the protective ground conductor for a neutral.

$115.00~~$145.00~~USD · shipping included · tax at checkout

Need a larger quantity or custom setup?

One-year warranty Personal product support

Seven-digit LCD energy display (5 + 2 digits).

Far-infrared and RS485 data communication for compatible AMR systems.

Passive pulse outputs with a specified rate of 10 kWh per pulse.

Automatic current-flow direction detection with an LCD indication.

PRODUCT OVERVIEW

Get to know the BY1248D.

A direct-connect DIN rail active-energy meter with Modbus/RTU, RS485, and far-infrared communication for single-, two-, or three-phase systems with up to four wires.

Current rating requires confirmation (80 A / 100 A); contact Beyondtech before purchase or installation. Confirm the continuous-current rating and the supplied model for your application. Discuss external-CT configurations separately to ensure the correct meter is supplied.

Applications include submetering for marinas, campgrounds, condominiums, tenant buildings, and rental apartments. A neutral is required. Installation must be completed by a qualified electrician using the correct model-specific wiring diagram.

Model reference BEYDTS5188 features Class 1 active-energy measurement, a seven-digit LCD, and interfaces for compatible AMR systems and pulse readers. Confirm the supplied model when ordering.

Features & capabilities

Seven-digit LCD energy display (5 + 2 digits).
Far-infrared and RS485 data communication for compatible AMR systems.
Passive pulse outputs with a specified rate of 10 kWh per pulse.
Automatic current-flow direction detection with an LCD indication.
Six LEDs indicate supply, energy pulse, remote pulse, and communication status.
35 mm DIN rail mounting or front-board mounting with 63 mm hole spacing.
Ten-pole width, using a 12.5 mm module; short terminal covers supplied.
An extended terminal cover and a configuration without data communication may be available on request.
